01009855 GE EPC611B10 Leistungsschalter
EPC611B10
5413656926924
692692
auf Anfrage
je
1 ST
keine Verfügbarkeitsinformationen
Verpackungseinheiten
1 ST | Menge übernehmen |
Funktionen
Verkaufsdaten
Mindestbestellmenge | 1 ST |
Bestellschritt | 1 ST |
Beschreibung
50% Platzersparnis durch die Unterbringung von zwei Schaltkreisen pro TE, DIN EN/IEC 60898-1; 609747-2,
230 V, 1P + 1P, getrennt schaltbar, 1TE, Anschlussklemmen: 2x max. 16mm2 Unibis™. Leitungsschutzschalter sind eine der Neuerungen der ElfaPlus-Palette und wurden entwickelt, um die Größe des Platzbedarfs auf das absolute Minimum zu reduzieren. Brandneues Design 2P in 1 TE, 3&4P in 2 TE. 2 bis 32 A, B- und C-Charakteristik, 6 kA. 100% kompatibel mit allen ElfaPlus Anbauteilen und Zubehör. 100% Qualität und Verlässlichkeit. CEBEC, NF, VDE, KEMA, IMQ Zertifikat. , Unibis™: Quality and reliability guaranteed. High performance clips: To fix the MCB to the DIN rail. High performance torque: Up to 3Nm. Easy to replace: Double clips makes it easy to replace the MCB’s, especialy when a busbar is installed. Userfriendly: All screws are on the same level to work fast and easy. Green or red flag on toggle with isolation applications: Correct information about the real position. Minimum 5mm distance between open contacts is ensured. Part of the family: Unibis™ MCB’s fit perfectly in the ElfaPlus range. Safety terminals IP20: The capacity of Unibis™ terminals has been doubled. Connection possibilities: 2 x 4mm² or (1 x 4mm²) + (1 x 6mm²). Saving up to 50% space in distribution boards!
230 V, 1P + 1P, getrennt schaltbar, 1TE, Anschlussklemmen: 2x max. 16mm2 Unibis™. Leitungsschutzschalter sind eine der Neuerungen der ElfaPlus-Palette und wurden entwickelt, um die Größe des Platzbedarfs auf das absolute Minimum zu reduzieren. Brandneues Design 2P in 1 TE, 3&4P in 2 TE. 2 bis 32 A, B- und C-Charakteristik, 6 kA. 100% kompatibel mit allen ElfaPlus Anbauteilen und Zubehör. 100% Qualität und Verlässlichkeit. CEBEC, NF, VDE, KEMA, IMQ Zertifikat. , Unibis™: Quality and reliability guaranteed. High performance clips: To fix the MCB to the DIN rail. High performance torque: Up to 3Nm. Easy to replace: Double clips makes it easy to replace the MCB’s, especialy when a busbar is installed. Userfriendly: All screws are on the same level to work fast and easy. Green or red flag on toggle with isolation applications: Correct information about the real position. Minimum 5mm distance between open contacts is ensured. Part of the family: Unibis™ MCB’s fit perfectly in the ElfaPlus range. Safety terminals IP20: The capacity of Unibis™ terminals has been doubled. Connection possibilities: 2 x 4mm² or (1 x 4mm²) + (1 x 6mm²). Saving up to 50% space in distribution boards!
Merkmale
Schutzart (IP) | IP20 |
Spannungsart | AC/DC |
Verpackungseinheit | 1 |
Gewicht | 0,39 |
Gewichtseinheit | KG |
Gewichtbezugsmenge | 1 |
Statistische Warennummer | 85362010 |
Einbautiefe | 44 mm |
Bemessungsstrom | 10 A |
Bemessungsspannung | 230 V |
Frequenz | 60 Hz |
Auslösecharakteristik | B |
Energiebegrenzungsklasse | 3 |
Überspannungskategorie | 3 |
Verschmutzungsgrad | 2 |
Breite in Teilungseinheiten | 1 |
Polzahl (gesamt) | 1 |
Bemessungsisolationsspannung Ui | 500 V |
Anzahl der abgesicherten Pole | 2 |
Anschließbarer Leiterquerschnitt eindrähtig | 35 mm² |
Anschließbarer Leiterquerschnitt mehrdrähtig | 25 mm² |
Umgebungstemperatur während des Betriebs | 55 °C |
Zusatzeinrichtungen möglich | ja |
Bemessungsschaltvermögen Icn nach EN 60898 bei 230 V | 6 kA |
Bemessungsschaltvermögen Icu nach IEC 60947-2 bei 230 V | 6 kA |
Bemessungsstoßspannungsfestigkeit Uimp | 6 kV |
Kurzbeschreibung | EPC611 UNIBIS Leitungsschutzschalter 6kA B 1P+1P 10A, MCB Miniature circuit breaker UNIBIS EPC 611 6kA B 1P+1P 10A GE |
